Description

Direct reading personal dosimeter for personnel exposure monitoring.

EcotestCARD can be used either independently with PDC Ecomonitor software or within the automated system of personal dosimetry control ASIDC-21.

The dosimeter allows storing dose accumulation history with real time reference in the non-volatile memory, and communicating it to the computer. If the programmed threshold levels of gamma dose or its rate are exceeded, light and audio alarms are actuated.

  • Сonforms to the CE standards
  • Meets the requirements of IEC 61526 standard
  • IP54

Purpose of Use

  • Measurement of gamma and X-ray radiation individual dose equivalent rate (DER).
  • Measurement of gamma and X-ray radiation individual dose equivalent (DE).
  • Clock, alarm clock.

Features

  • Stand-alone use or use within automated system of personal dosimetry control.
  • Storage of dose accumulation history in the nonvolatile memory with real time reference.
  • Transfer of dose accumulation history through the infrared port to the computer.
  • Blocking the mode of power supply switch off until the data reading procedure finished.
  • DER and DE threshold levels programming of gamma and X-ray radiation with the help of the computer or manually with control keys.
  • Blocking certain indication modes in response to the computer command.
  • Light and audio alarms when programmed threshold levels exceeded on DER and DE of gamma and X-ray radiation.
  • Display automatic switch off if current gamma background is lower than the preset threshold level with instant switching on at:
    • pressing any control key;
    • gamma background increase above the preset threshold level;
    • alarm clock ringing.
  • Periodic self-testing of batteries and detector.
  • Energy-compensated Geiger-Muller counter.

Specifications

Measurement ranges and main relative errors:

  • gamma and X-ray radiation individual dose equivalent rate HP(10)
    0.1…1 000 000 µSv/h
    (1…10 µSv/h; ±20%;10 µSv/h…1 Sv/h; ±10%)
  • gamma and X-ray radiation individual dose equivalent HP(10)
    0.001…9 999 mSv ±15%
  • Energy range of detected gamma and X-ray radiation and energy dependence
    0.05…6.0 MeV (0.05…1.25; ±25%)
  • Recording resolution of dose accumulation history in the nonvolatile memory
    5…255 minutes
  • Time of data storage in the nonvolatile memory
    not less than 10 years
  • Data exchange rate through infrared port
    38 400 bit/s
  • Positive data exchange distance between the dosimeter and the infrared port adapter
    not more than 0.3 m
  • Lithium battery (CR2450) life*
    2 200 hours
  • Operating temperature range
    -20…+50 °C
  • Weight
    0.14 kg
  • Dimensions
    56x96x16 mm
